C181B, Marathon, 1HP, 115/208-230V, Electric Motor

Marathon C181B
The specs and drawing below are for your assurance of same fit and function.

Nameplate Specifications
===================
Output HP 1
Frequency 60 Hz
Voltage 115/208-230 V
Current 8.0/4.4-4.0 A
Speed 1725 rpm
Service Factor 1.25
Phase 1
Efficiency 82.6 %
Power Factor 96
Duty Continuous
Insulation Class B
Frame 56
Enclosure Drip Proof
Thermal Protection No Protection
Ambient Temperature 40 °C
Drive End Bearing Size 6203
Opp Drive End Bearing Size 6203
UL Recognized CSA Y
CE Y IP Code 22

Technical Specifications
==================
Electrical Type Capacitor Start Capacitor Run
Rotation Selective Counterclockwise
